Low Noise Portable Plate Edge Milling Machine Smooth Cutting Simple Operation

1. Feed torque is improved again,More stable processing performance,The smooth finish of the groove

reaches Ra3.2-6.3

2. The groove angle of the equipment can be adjusted freely between 30° and 60°.

3. easy to use,Easy to learn,Ordinary workers can operate multiple devices at the same time

4. Single maximum slope width 10mm,Up to 18mm multiple times

5. Milling cold working method,The processed groove surface is not oxidized,Stainless steel groove can

be welded without pickling

6. Can be processed for small and medium plates,Knife tray with 4 blades,Each group can process 800-

1200m,Very low consumables

Product description and main performance

This machine is also called stationary edge milling machine, mainly using the milling principle of small

plates need large groove milling edge and dedicated to the development of new products. Table edge

milling machine product single processing edge milling width of 10 mm, the maximum processing to 18mm

edge width. Compared with the general machine type, the processing capacity of table milling edge

machine is unmatched by other machine types. The machine innovatively USES the rolling driven wheel

device, which eliminates manual piling, and the material can be self-feeding after entering the material

port, making the feeding easier when the machine works. Applicable to common structural steel, stainless

steel, cast iron, hard plastics, non-ferrous metals and other materials. It is a special tool for cutting edge

of welding front end face. This machine has the advantages of smooth surface, easy to use, low labor

intensity, high efficiency and low cost. It solve that problems of flame cut, grinding of polishing machine,

large-scale milling machine, etc., the product is cheap and beautiful, and the small machine can be used

as the best partner in the edge milling operation of your small material
