Zhejiang Wellnit Mechanical Technology Co.,Ltd
Adhered to customer satisfaction as the goal, to pioneering innovation as the driving force, to honesty and trust worthiness as the principle, to quality and low price as the pursuit!
|
Product Details:
Payment & Shipping Terms:
|
| Power: | AC 380V 50Hz | Total: | 2800W |
|---|---|---|---|
| Net Weight: | 80Kg | Bevel Width: | 1-18mm |
| Clamp Thickness: | 2-40mm | ||
| High Light: | handheld milling machine,hand held plate beveler |
||
2800W Anti Rust Small Table Plate Edge Beveling
Machine , Plate Beveler
1. Feed torque is improved again,More stable processing performance,The smooth finish of the groove
reaches Ra3.2-6.3
2. The groove angle of the equipment can be adjusted freely between 30° and 60°.
3. easy to use,Easy to learn,Ordinary workers can operate multiple devices at the same time
4. Single maximum slope width 10mm,Up to 18mm multiple times
5. Milling cold working method,The processed groove surface is not oxidized,Stainless steel groove can be
welded without pickling
6. Can be processed for small and medium plates,Knife tray with 4 blades,Each group can process 800-
1200m,Very low consumables
Main performance of the product
PB-10D small table plate milling machine.The finish of the groove is as
high as Ra 3.2-6.3,and the machine is suitable for high hardness material
such as carbon steel,stainless steel,aluminum alloy and other materials.
It includes groove processing for high degree of smoothness of beveling
machine.
Technical Parameter
| PB-10D | |
| Power Supply | AC 380V 50HZ |
| Power | 2600W |
| Spindle Speed | 1440r/min |
| Feed Speed | 0~1500mm/min(Adjustable) |
| Bevel Width | 1~18mm |
| Maximum Milling Width | 10mm |
| Bevel Angle | 15°~75°(Adjustable) |
| Clamp Thickness | 2~40mm |
| Clamp Width | >20mm |
| Net Weight | 80Kg |
| Processing Materials | Carbon Steel, Stainless Steel, Aluminium Alloy, Etc |
The product description
The chamfered beveling machine developed for small-sized plates is equipped with high-strength
polyurethane as the pressure wheel, which can realize continuous rolling compaction, and the high-
efficiency and stable processing can be realized for the bar plate and the small plate. The small size of the
plate is more suitable, and the pb-10d groove with its strong power and high efficiency has been highly
praised by many customers, with its smooth and clean surface and high efficiency and convenient
movement.
This machine mainly USES the principle of milling, milling the edge of the steel plate according to the
desired Angle, so as to obtain the necessary groove for welding. Applicable to common structural steel
, stainless steel, cast iron, hard plastic, non-ferrous metals and other materials! The flat beveling machine
is chamfered on the end face before welding
The special tool of groove solves the defects such as improper Angle, rough slope surface and loud
working noise of operation process such as flame cutting and grinding by grinding machine
, can automatically walk according to the material edge automatically, this machine has the adjustment
Angle convenient, the operation convenient, the unit time efficiency is high, the environmental protection
has the operation simple, the Angle standard, the surface is smooth.
