Explosion Proof Pneumatic Pipe Beveler

Explosion Proof Pneumatic Pipe Beveler
Explosion Proof Pneumatic Pipe Beveler
video play

Large Image :  Explosion Proof Pneumatic Pipe Beveler

Product Details:
Place of Origin: China
Brand Name: Wellnit
Certification: ISO9001
Model Number: ISP
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Plywood
Delivery Time: within 3days
Payment Terms: T/T
Supply Ability: 180 set / month
Detailed Product Description
Mounted Way: Inside Mounted Working Range (I.D): 18-840mm
Wall Thickness: Less Than 75mm Function: Explosion Proof
High Light:

Explosion Proof Pneumatic Pipe Beveler

,

Inside Mounted Pipe Beveler Machine

,

ID 18mm Pneumatic Pipe Beveler



Explosion Proof Pneumatic Stainless Steel Pipeline end Beveling Machine



This series of machine have two driven way. Electric and Pneumatic. It is high cost efficiecny machine. Pneumatic Driven Machine can explosion proof. more safety. Electric Driven , not need air compressor, easy to operation. The machine is internal mounted , small raduis, suitable for any working condition.The machine compact design , light weight , easy to carry to anywhere, suitable for repair in the field. Also machine can make stationary table for factory working line processing. The machine have competitive price. good price and good quality. this series machine are the most popular machine.The machine can outside bevel , inside bevel , tube facing , counter boring etc function.

Explosion Proof Pneumatic Pipe Beveler 0
Function of products

  • Pneumatic Driven , Explosion Proof
  • Compact design , Light Weight
  • Inside Mounted , Small Raduis
  • Manual Operation , High efficiency
  • Bevel angle can be adjustable
  • Working Range (18-840mm)
  • Wall thickness less than 75mm
  • Outside Bevel , Inside bevel , Tube facing , counter boring
  • Bevel Type: V , U , X etc
  • Pipe material: carbon steel , stainless steel , aluminum alloy etc
  • Machine Drievn : Electric ; Pneumatic


Specification of Products



Model Working Range (I.D) Wall thickness Rotation Speed
ISE-30 18-28mm less than 15mm 50r/min
ISE-80 28-76mm less than 15mm 55r/min
ISE-120 40-120mm less than 15mm 30r/min
ISE-159 65-159mm less than 20mm 35r/min
ISE-252-1 80-240mm less than 20mm 16r/min
ISE-352-1 150-330mm less than 20mm 14r/min
ISE-426-1 250-426mm less than 20mm 12r/min
ISE-630-1 300-600mm less than 20mm 10r/min
ISE-850-1 600-840mm less than 20mm 9r/min
ISE-252-2 80-240mm less than 75mm 16r/min
ISE-352-2 150-330mm less than 75mm 14r/min
ISE-426-2 250-426mm less than 75mm 12r/min
ISE-630-2 300-600mm less than 75mm 10r/min
ISE-850-2 600-840mm less than 75mm 9r/min




Application Range
The machine widely used in the fields of petroleum , Chemical , natural gas ; Power supply construction ; boiler and nuclear power etc

  • Site construction of high sulfur pipelines
  • on site construction of TUHA oil field
  • natural gas storage pipeline project
  • petro chine pipeline project
  • china Russia pipeline project
  • inspection and repair of pipeline in large power plants
  • emergency repair of nuclear industry equipment
  • project of west gas transporting to east china


Bevel Type

Outside bevel , Inside bevel , tube facing , counter boring etc

"V" Tybe ; "U" Tybe ; "X" Tybe etc

Explosion Proof Pneumatic Pipe Beveler 1
Explosion Proof Pneumatic Pipe Beveler 2Explosion Proof Pneumatic Pipe Beveler 3

Order Guide

  • pipe size (I.D)
  • pipe thickness
  • pipe material
  • Machine Driven : Electric ; Pneumatic
