55mm Bevel Width 3400W 90 Degree Plate Beveling Machine

China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
I'm Online Chat Now

55mm Bevel Width 3400W 90 Degree Plate Beveling Machine

55mm Bevel Width 3400W 90 Degree Plate Beveling Machine
55mm Bevel Width 3400W 90 Degree Plate Beveling Machine
video play

Large Image :  55mm Bevel Width 3400W 90 Degree Plate Beveling Machine

Product Details:
Place of Origin: China
Brand Name: Wellnit
Certification: ISO9001
Model Number: PB-60L
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Plywood Box
Delivery Time: within 5 days
Payment Terms: T/T
Supply Ability: 10set / month
Detailed Product Description
Power Supply: AC 380V 50Hz Motor Power: 3400W
Bevel Angle: 0 To 90 Degree Bevel Width: 1-55mm
Clamp Thickness: 6-60mm
High Light:

90 Degree Plate Beveling Machine

,

3400W Plate Beveling Machine

,

Automatic Matching Plate Beveling Machine

Automatic Feed bevel angle 0- 90 degree plate beveling machine high efficiency





Performance of products

This series of machine special design for metal plate, bevel angle can be adjustable , can bevel plate facing , special for compound material plate .automatic feed ,automatic matching , one worker can processing several machine together,  several side of plate can processing together, more efficiency! Save labor and cost.Machine tool header can be choose. (have two tool header) according to process requirement choose. Machine can process small plate and big plate. can process thin plate and thick plate. bevel angle can be adjustable, bevel depth can be adjustble, high accurate.can process carbon steel , stainless steel , aluminum alloy , compound plate etc.







Function of products

  • Cold beveling , can not affect plate material
  • Automatic marching and feed, save labor and cost
  • Easy to operation , one worker can operation seversal machine together,high efficiency
  • Bevel angle and depth both can be adjustable , high accurate
  • small or big plate , thin or thick plate , both can processing
  • plate material: carbon steel , stainless steel , aluminum alloy , compound plate etc.
  • Bevel Type : V , U  , X , compound bevel etc

Tool Header



55mm Bevel Width 3400W 90 Degree Plate Beveling Machine 0



Bevel Type

55mm Bevel Width 3400W 90 Degree Plate Beveling Machine 1



Difference:

  • PB-60L can do 0degree and 90degree bevel.
  • “ J ” Bevel type only PB-60L (A Tool Head) can do it. (R6)
  • Compound bevel (Type 2) bevel type only PB-60L (B Tool Head) can do it.



Machine Specification


55mm Bevel Width 3400W 90 Degree Plate Beveling Machine 2



Order Guide

  • Plate length
  • Plate width
  • Plate thickness
  • Plate material
  • Plate condition : Straight Blade or Curved Plate ?
  • Bevel Angle
  • Bevel depth
  • Processing Drawing
