3 M/min Pneumatic Portable Plate Beveling Machine No Vibration Easy To Operation



3 M/min Pneumatic Portable Plate Beveling Machine



No Vibration Easy To Operation





Product features and scope of application



The high precision pneumatic hand chamfering machine adopts imported machine core structure, which



can achieve chamfering effect while ensuring the accuracy during processing. It not only has the



characteristics of light and flexible operation, but also can be adjusted freely from the r1-r3mm chamfering



surface.

Pb-r3 chamfering machine is a high-power product developed by our company to absorb foreign



products. The machine has high power and smooth operation. Using carbide blade, 8 working surfaces



are available, safe to use, stable in size, long blade life, high cutting efficiency, suitable for edge, hole,



Angle R and C surface chamfer of sheet metal in the fields of shipbuilding, frame, bridge, etc.







PB-R3
Dimension	Underpan 150, Height 160
Tool Bits Qty	3pcs
Min imum Working radius	R16
Milling Angle	R1-3
Plate Thickness	≥9mm
Weight	3.9Kg
Milling speed	3m/min
Air Hose I.D	≥10
Air pressure	0.4-0.63MPa







The product description



Pb-r3 handheld pneumatic chamfering machine is simple in design, easy to operate and compact in



appearance. It is widely used in many large shipbuilding enterprises at home and abroad. Zhejiang winnett



machinery technology co., LTD. According to the foreign product technology innovation, combine the



continuous practice and improvement. Further increase the power of pb-r3 and make the operation more



stable. The blade adopts R3 blade which is universal in pneumatic chamfering machine. In many



shipbuilding enterprises, steel structure, metal mold and other industries have been recognized by



customers and praise!







Technology leadership, witness strength


1: the chamfering effect is smooth and smooth


Light weight, easy to operate, can reduce the labor intensity of the operator, not easy fatigue, safety and



other features


And durable. Parts wear resistant and low maintenance cost.


2. Compared with the polishing machine, it has the following advantages:


High cutting efficiency and increased efficiency by 10-30 times. Chamfering effect smooth, smooth finish.



Reduce grinding intensity, avoid dust, safety and environmental protection. Flexible and convenient



operation.


3: imported bearing


The smoothness of cutting is 1.6. Compared with the chamfering machine without this technology, the



smoothness can be increased by 3 times.


4. Profile design is adopted for chamfered trajectory


Straight edge, curve, u-shaped groove, inner and outer hole and any irregular curve can be processed,



making your cutting more flexible.


5. The main engine adopts the patented anti-vibration control technology. The smaller the vibration, the



safer the work


Heavy work such as cutting requires the use of powerful chamfering equipment. But the resulting high



frequency vibrations can have adverse effects on the operator, such as arm vibration syndrome (HAVS).



All employees are well aware of the health risks associated with high frequency vibration. The



consequences of excessive strain often take years to emerge, and vibration protection is an investment in



your employee's health and ability to work. Protect your employees, protect yourself.


6: the blade is made of cemented carbide, with three edges available for design


One blade, eight blades. Save more cost of consumables for you.


7: quick change connection of air source allows easy maintenance between machine use and non-use.





Pb-r3 pneumatic chamfer is a light chamfer with a weight of less than 4KG. The rubber handle can be



used by both hands



General chamfering machine performance is the same, removing the auxiliary handle can be the right



hand holding machine, left hand holding material for small pieces of chamfering. using



Three blades, each blade has 8 working faces, low consumption of blades, and blade handling and



adjustment is very convenient and widely applicable



Chamfering of edge, hole and corner of sheet metal in the field of shipbuilding, frame and bridge.
