1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher

1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher
1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher 1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher 1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher

Large Image :  1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher

Product Details:
Place of Origin: CHINA
Brand Name: Wellnit
Certification: ISO 9001
Model Number: OCE
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2100
Packaging Details: plywood
Delivery Time: within 2days after received 100% payment
Payment Terms: T/T
Supply Ability: 10 Sets per month
Detailed Product Description
Structure: Split Frame Wall Thickness: Less Than 30mm (Standard)
Working Range (O.D): 25-1430mm Material: Carbon Steel ,stainless Steel , Aluminum Alloy Etc
High Light:

pipe cutter and beveler

,

pipe bevel cutter

1"-56" working range Pipe cold cutter Machine pipe end surface polisher



The Product introduce

The series of products is ideal for all types of pipe cutting ,beveling and end preparation.suitable for small factory and rush repair work in the field.It is outside Mounted , the O.D of the in-line pipe or fittings for strong,stable clamping.Can cutting and bevel at same time. save time, High Efficiency,High Precision.

The equipment performs precision in-line cut or sumultaneous cut / bevel , single point , counterbore and flange facing operation. The product also call weld prepare equipment. it weld end preparation on the open ended pipe , Range from 1"-56" (DN 25-1430mm) , on most wall thickness and material.



The function of Product

(1) internal mounted,small radius,suitable for narrow situation

(2) light weight , easy to carry out.

(3) Cold process, can't effect the material of pipe , no spark , no burr.

(4) cutting and beveling simultaneously,high efficiency.

(5) Can separate to two half, can mounted any position

(6) Process carbon steel , stainless steel, aluminum alloy etc

(7) bevel degree can be customization,U,V,J compound bevel both can process

(8) Driven:Electric,Pneumatic,Hydraulic,Metabo

All machines within products introduction ,manuals in english which is having all the operation.

Widely used in petroleum,chemical,boiler pipeinstall etc industry.



1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher 0



The specification of product

Driven Model Working Range(I.D-O.D) Wall Thickness Rotation Speed
  89 25-89 1"-3"   42r/min
  159 50-159 2"-5"   20r/min
  168 50-168 2"-6"   18r/min
  230 80-230 3"-8"   15r/min
  275 125-275 5"-10"   14r/min
OCE 305 150-305 6"-10"   13r/min
Electric 325 168-325 6"-12"   13r/min
  377 219-377 8"-14" Standard 12r/min
OCP 426 273-426 10"-16" <=30mm 12r/min
Pneumatic 457 300-457 12"-18"   12r/min
  508 355-508 14"-20"   12r/min
OCH 560 400-560 16"-22"   12r/min
Hydraulic 610 457-610 18"-24"   11r/min
  630 480-630 20"-24" Heavy-Duty 11r/min
OCM 660 508-660 20"-26" <=100mm 11r/min
Metabo 715 560-715 22"-28"   11r/min
  762 600-762 24"-30"   11r/min
  830 660-813 26"-32"   10r/min
  914 762-914 30"-36"   10r/min
  1066 914-1066 36"-42"   10r/min
  1230 1066-1230 42"-48"   10r/min
  1430 1230-1430 48"-56"   8r/min
Note:Non-Standard Machines are available according to customer's requirement.



OCE mean that driven is Electric



OCP mean that driven is Pneumatic

Pnuematic driven need meet air requirements.

Power supply:0.8-1.0MPa

Air consumption:1000-2000L/Min



OCH mean that driven is Hydraulic

need have hydraulic station



OCM mean that driven is Metabo



Different Model that Working Range is different.



About the machine Warrenty.

One year.(Except for improper operation)



If there are same problems with operation,we will provide you with free technical support.



The Opeation general steps as follows:

1.Measure pipe size(O.D),choose suitable block and install.

2.put machine on the pipe,fixed the machine

3.install the tools

4.start to process



1"-56" Working Range Pipe Cold Cutter Machine Pipe End Surface Polisher 1



In the Picture, This our cutting tools and beveling tools

If you just want to cutting ,you can install two cutting tools

If you just want to beveling , you can install two beveling tools

Our machine standard equipped with four tools

2pcs cutting tools and 2pcs beveling tools (30degree and 37.5degree)



We are manufacturers, we have professional engineers,

you provide processing requirements and drawings,

we will customize products for you to meet your needs.

We also can video with you,let our engineers teach you how to use machine.



Before place order ,please provide more details about your pipe,

We will recommend suitable machine to you.

1.PIPE SIZE (O.D):

2.PIPE THICKNESS:

3.PIPE MATERIAL:

4.DRIVEN:
