Home ProductsPipe Cutting And Beveling Machine

High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment

China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
I'm Online Chat Now

High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment

High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment
High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment

Large Image :  High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment

Product Details:
Place of Origin: China
Brand Name: Wellnit
Certification: ISO9001
Model Number: OC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $2880
Packaging Details: Plywood
Delivery Time: About a week
Payment Terms: T/T
Supply Ability: 30 sets per month
Detailed Product Description
Working Range: 1inch To 56inch Wall Thickness: Less Than 30mm (Standard)
Rotation Speed: 8-42r/min Material: Carbon Steel ; Stainless Steel ; Alloy Etc
Driven: Electric ; Pneumatic ; Hydraulic ; Metabo ; Servo Motor Warranty: One Year
High Light:

pipe cutter and beveler

,

pipe bevel cutter



Split Frame Cold Pipe Cutting And Beveling Machine High Efficiency

Machine Performance

The ID-Mounted beveling operation utilizes an expandable mandrel which is slid into the open end of the pipe.A draw nut is tightened,which expands the mandrel blocks up a ramp and against the ID surface for positive mounting,self centered and squared to the bore. As the tool bit is fed into the material from the end,a bevel is produced which conforms to the angle predetermined by the angle ground into the bit.Bits are available for practically any material or beveling angle required,and bits can be custom made for any form tooling operation.

Features:

  • On-site cold Beveling improves safety
  • Easy set-up & Operation
  • Self-Centering
  • Can be positioned in any direction
  • Feed ratchet spanner makes tool feed / back easily
  • Light weight and compact design
Spcification:
High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment 0


Our service

  • Choose the right Model

  • Confirm your electric power supply ( Voltage, frequency and phase)

  • Confirm the beveling angel required

  • Confirm the welding joint required (U, V, Double V or Compound preparation)

  • Advise your pipe material ( Carbon steel, stainless steel or others)

  • Other special demands about machine

  • The spare parts needed

  • If the pipe wall thickness more than 30mm, inform us in advance (Important)

High Efficiency Bevel Cutting Machine For Pipes , Cold Cutting Pipe Equipment 1
