Product Details:
Payment & Shipping Terms:
|
| Total Power: | 2450W | Power Supply Voltage: | AC 220V 50Hz |
|---|---|---|---|
| Bevel Width: | 1-18mm | Processing Speed: | 500-1500mm/min |
| Bevel Angle: | 20-60 Degrees | Number Of Blades: | 4/5 |
Product performance:
1. Cold working, no sparks, and will not affect the material;
2. The machine is compact in structure, light in weight and easy to carry;
3. Milling processing, smooth slope and high surface finish;
4. Small working radius, suitable for any working space, fast beveling and deburring;
5. Equipped with CNC milling blades, CNC CNC blades, low consumables;
6. It can process curved plates, straight plates, special-shaped plates, plate holes, round pipes, square pipes, etc.
7. Groove form: V, Y, X type, R angle, etc.
| Product parameter | |||
| Voltage | 220-240V | Motor Power | 2450W |
| working frequency | 50/60Hz | Safety | Soft start |
| Bevel angle | 30 Standard20 37.5 45 Optional | Slope width | 1-18mm(Q235) |
| Cutter speed | 2500-7500r/min | Host weight | 8.5KG |
| Machinable material | Can process curved plates, straight plates, special-shaped plates, plate holes, round pipes, square pipes, etc. | ||
