Product Details:
Payment & Shipping Terms:
|
| Voltage: | AC 3PH 380V 50HZ | Total Power: | 1100w |
|---|---|---|---|
| Clamp Thickness: | 5-15mm | Bevel Angle: | 30°；37.5°；45° |
| Rotation Speed: | 2000 R/min | Pipe Min ID Size: | 133mm |
| High Light: | Multifunctional Electric Pipe Beveling Machine,Electric Pipe Beveling Machine 1100w,2000r/Min Electric Pipe Beveling Machine |
||
Main Features
1. Cold Processed, No spark, Will not affect the material of plate.
2. Compact Structure, Light weight, Easy to carry
3. Unlimited working range (pipes above 133mm can be processed)
4. Smooth slope, Surface finish can be as high as Ra3.2- Ra6.3.
5. Small working radius, Suitable for any working space,fast beveling and deburring, High efficiency.
6. Equipped with CNC blades, low consumables.
7. Bevel type:K, V, Y,X etc.
8. Can process straight plates and round tubes.
Specification
| Voltage | AC 3PH 380V 50HZ |
| Total Power | 1100W |
| Clamp Thickness | 5-15mm |
| Bevel Angle | 30°; 37.5°; 45° |
| Rotation Speed | 2000r/min |
| Pipe Min ID Size | 133mm |
| Bevel Width | 1-15mm |
| Tool Bit Qty | 4Pcs |
| Net Weight | 25kgs |
| Gross Weight | 30kgs |
| Machine Dimension | 485*405*290mm |
| Process Material | CS,SS,AluminumAlloy ,Bronze etc |
