Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz

China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
China Zhejiang Wellnit Mechanical Technology Co.,Ltd certification
I'm Online Chat Now

Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz

Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz
Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz

Large Image :  Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz

Product Details:
Place of Origin: China
Brand Name: Wellnit
Certification: ISO9001
Model Number: ISE-80
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: plywooden
Delivery Time: within 7 days after received 100% payment
Payment Terms: T/T
Supply Ability: 50 sets for a mounth
Detailed Product Description
Power Supply: 220-240V 50-60Hz Driven: Electric
Thickness: Less Than 15 (Standard) Speed Rotation: 55r/min
Working WAY: No Spark,Cold Working Fix Way: Inside Mounted
Motor Power: 1600W Working Range: 28-76mm(ID-OD)
High Light:

tube facing machine

,

portable pipe beveler



Automatic ISE Electric Pipe Beveling Machine Stable Operation 50Hz / 60Hz





Main performance of the product



This series is ID-Mounted pipe beveling machine,with the following advantages:Easy operation, light weight and convenient to carry. The ID-Mounted pipe beveling machines use expanding mandrel to holding itself against on the internal surface of pipe via the open end of pipe. A draw nut is tightened,Which expands the mandrel blocks up a ramp and against the ID surface for positive mounting,self centered and squared to the bore.It's can work with various material pipe,beveling angle as per your required.





Technical characteristics







This series is ID Mounted Welding Preparation Pipe Chamfering Tool with the following advantages:

  • Lighter weight,minimal radial space,Easy to operate.
  • A draw nut is tighted,which expands the mandrel blocks up a ramp and against the ID surface for positive mounting,self centered and squared to the bore.
  • Driveing Type:Electric-ISE,Pneumatic-ISP.
  • Can Be Process Diffferent Material Pipe:Carbon Steel,Stainless Steel,Alloy And Ohers.
  • Angle:Beveling angle as per your required.

  •



Technical Parameter





ISE-80 Beveling Machine
Voltage 220-240V
Frequency 50/60Hz
Power 1600W
Wall Thickness ≦15
Working Range 28-76mm
Rotation Speed 55r/min
Net Weight 16kg




Non-standard machines are available according to customers’requirement.
